Size and weight

• Height: 1.4 inches (3.6 cm)

• Width: 7.7 inches (19.7 cm)

• Depth: 7.7 inches (19.7 cm)

• Weight: 3.0 pounds (1.37 kg)^

Processor and memory

• 2.4GHz or 2.66GHz Intel Core 2 Duo processor

• 3MB on-chip shared L2 cache

• 1066MHz frontside bus

• 2GB (two 1GB SO-DIMMs) of 1066MHz DDR3 SDRAM; two SO-DIMM slots support up to 8GB

Environmental Status Report

Mac mini is designed with the following features to reduce its environmental impact:

• BFR-free

• PVC-free

• Highly recyclable aluminum enclosure

• Meets ENERGY STAR 5.0 requirements

• Rated EPEAT Gold

Acoustic Performance

DECLARED NOISE EMISSIONS in accordance with ISO 9296

1. L_WAd is the statistical upper-limit A-weighted sound power level (rounded to the nearest 0.1 B).

2. L_pAm is the mean A-weighted sound pressure level measured at the operator position (rounded to the nearest dB).

3. 1 B (bel) = 10 dB (decibel).

Peripheral connections

• One FireWire 800 port (up to 800 Mbps)

• Four USB 2.0 ports (up to 480 Mbps)

• SD card slot

Graphics and video support

• NVIDIA GeForce 320M graphics processor with 256MB of DDR3 SDRAM shared with main memory

• Mini DisplayPort with support for up to 2560-by-1600 resolution

• HDMI port with support for up to 1920-by-1200 resolution

• DVI output using HDMI to DVI Adapter (included)

• VGA output using Mini DisplayPort to VGA Adapter (sold separately)

• Support for extended desktop and video mirroring across both ports

Communications

• AirPort Extreme 802.11n Wi-Fi wireless networking; IEEE 802.11a/b/g compatible

• Bluetooth 2.1 + EDR (Enhanced Data Rate) wireless technology

• 10/100/1000BASE-T Ethernet (RJ-45) interface with support for jumbo frames

Audio

• Audio line in minijack (digital/analog)

• Audio line out/headphone minijack (digital/analog)

• HDMI port supports multichannel audio output

• Support for Apple iPhone headset with microphone

Storage

• 320GB or 500GB Serial ATA hard disk drive

• 8x slot-loading SuperDrive (DVD±R DL/DVD±RW/CD-RW)

  • Maximum read: 8x DVD-R, DVD+R, DVD-ROM, DVD-ROM (double layer DVD-9), DVD-R DL (double layer), DVD+R DL (double layer), DVD-RW, and DVD+RW; 24x CD

  • Maximum write: 8x DVD-R, DVD+R; 6x DVD-R DL (double layer), DVD+R DL (double layer), DVD-RW; 8x DVD+RW; 24x CD-R; 24x CD-RW

Configurable options

Electrical and operating requirements

• Line voltage: 100-240V AC

• Frequency: 50Hz to 60Hz, single phase

• Maximum continuous power: 85W

• Operating temperature: 50° to 95° F (10° to 35° C)

• Storage temperature: -40° to 116° F (-40° to 47° C)

• Relative humidity: 5% to 95% noncondensing

• Maximum altitude: 10,000 feet

• Typical acoustical performance

  • Sound pressure level (operator position): 14 dBA at idle
