2.3GHz Mac mini

2.5GHz Mac mini

Size and Weight

The perfect fit for any desk.

• Height:1.4 inches (3.6 cm)

• Width:7.7 inches (19.7 cm)

• Depth:7.7 inches (19.7 cm)

• Weight:2.7 pounds (1.22kg)¹

• Height:1.4 inches (3.6 cm)

• Width:7.7 inches (19.7 cm)

• Depth:7.7 inches (19.7 cm)

• Weight:2.7 pounds (1.22kg)¹

Processor and Memory

Powered by a dual-core Intel Core i5 or i7 processor and DDR3 memory.

Processor

2.3GHz dual-core Intel Core i5 with 3MB on-chip shared L3 cache

Processor

2.5GHz dual-core Intel Core i5 with 3MB on-chip shared L3 cache

Configurable to 2.7GHz dual-core Intel Core i7, only at the Apple Online Store.

Memory

2GB of 1333MHz DDR3 memory

Configurable to 4GB or 8GB, only at the Apple Online Store.

Memory

4GB of 1333MHz DDR3 memory

Configurable to 8GB, only at the Apple Online Store.

Storage

A 500GB hard drive comes standard.

500GB (5400-rpm) hard drive

Both models configurable to 750GB (7200-rpm) hard drive; 2.5GHz model also configurable to 256GB solid-state drive or 256GB solid-state drive and 750GB (7200-rpm) hard drive, only at the Apple Online Store.

Graphics

All-new graphics.

Intel HD Graphics 3000 processor with 288MB of DDR3 SDRAM shared with main memory^

AMD Radeon HD 6630M graphics processor with 256MB of GDDR5 memory

Video Support

Works with almost any display or HDTV.

• Thunderbolt port with support for up to 2560-by-1600 resolution

• HDMI port with support for up to 1920-by-1200 resolution

• DVI output using HDMI to DVI Adapter (included)

• Support for dual display and video mirroring

Audio

• Audio line in minijack (digital/analog)

• Audio line out/headphone minijack (digital/analog)

• HDMI port supports multichannel audio output

• Support for Apple iPhone headset with microphone

• Built-in speaker

Connections and Expansion

A new Thunderbolt port, an HDMI port, and plenty of peripheral ports.

• Thunderbolt port (up to 10 Gbps)

• FireWire 800 port (up to 800 Mbps)

• Four USB 2.0 ports (up to 480 Mbps)

• HDMI port

• SDXC card slot

• Gigabit Ethernet port

• Audio in/out

Communications

The latest Wi-Fi, Bluetooth, and Ethernet technologies.

Wi-Fi

802.11n Wi-Fi wireless networking;IEEE 802.11a/b/g compatible

Bluetooth

Bluetooth 4.0 wireless technology

Ethernet

10/100/1000BASE-T Ethernet (RJ-45 connector)

Electrical and Operating Requirements

• Line voltage: 100-240V AC

• Frequency: 50Hz to 60Hz, single phase

• Maximum continuous power: 85W

• Operating temperature: 50° to 95° F (10° to 35° C)

• Storage temperature: -40° to 116° F (-40° to 47° C)

• Relative humidity: 5% to 95% noncondensing

• Maximum altitude: 10,000 feet

• Typical acoustical performance

  • Sound pressure level (operator position): 16 dBA at idle
