Size and weight

• Height: 0.95 inch (2.41 cm)

• Width: 14.35 inches (36.4 cm)

• Depth: 9.82 inches (24.9 cm)

• Weight: 5.6 pounds (2.54 kg)^

Connections and expansion

• MagSafe power port

• Gigabit Ethernet port

• One FireWire 800 port (up to 800 Mbps)

• Mini DisplayPort

• Two USB 2.0 ports (up to 480 Mbps)

• SD card slot

• Audio line in

• Audio line out

• Kensington lock slot

Communications

• AirPort Extreme Wi-Fi wireless networking(based on IEEE 802.11n specification); IEEE 802.11a/b/g compatible

• Bluetooth 2.1 + EDR (Enhanced Data Rate) wireless technology

• 10/100/1000BASE-T Gigabit Ethernet (RJ-45 connector)

Audio

• Stereo speakers with subwoofers

• Omnidirectional microphone (located under left speaker grille)

• Audio line in minijack (digital/analog)

• Audio line out/headphone minijack (digital/analog)

• Support for Apple iPhone headset with microphone

Environmental Status Report

MacBook Pro is designed with the following features to reduce its environmental impact:

• Highly recyclable aluminum and glass enclosure

• Mercury-free LED-backlit display

• Arsenic-free display glass

• BFR-free

• PVC-free

• Reduced packaging volume

• Meets ENERGY STAR Version 5.0 requirements

• Rated EPEAT Gold

Acoustic Performance

DECLARED NOISE EMISSIONS in accordance with ISO 9296

1. L_WAdis the statistical upper-limit A-weighted sound power level (rounded to the nearest 0.1 B).

2. L_pAmis the mean A-weighted sound pressure level measured at the operator position (rounded to the nearest dB).

3. 1 B (bel) = 10 dB (decibel).

Display

• 15.4-inch (diagonal) LED-backlit glossy widescreen display with support for millions of colors

• Supported resolutions: 1440 by 900 (native), 1280 by 800, 1152 by 720, 1024 by 640, and 800 by 500 pixels at 16:10 aspect ratio; 1024 by 768, 800 by 600, and 640 by 480 pixels at 4:3 aspect ratio; 1024 by 768, 800 by 600, and 640 by 480 pixels at 4:3 aspect ratio stretched; 720 by 480 pixels at 3:2 aspect ratio; 720 by 480 pixels at 3:2 aspect ratio stretched

• Optional 15.4-inch (diagonal) LED-backlit widescreen display with 1680 by 1050 pixels (glossy or antiglare)

Graphics and video support

• NVIDIA GeForce GT 330M graphics processor with 256MB of GDDR3 memory on 2.4GHz and 2.53GHz configurations; or 512MB of GDDR3 memory on 2.66GHz configuration

• Intel HD Graphics with 256MB of DDR3 SDRAM shared with main memory

• Automatic graphics switching

• Dual display and video mirroring: Simultaneously supports full native resolution on the built-in display and up to 2560 by 1600 pixels on an external display, both at millions of colors

• iSight camera

• Mini DisplayPort

Pure digital video output

DVI outputusing Mini DisplayPort to DVI Adapter (optional)

VGA outputusing Mini DisplayPort to VGA Adapter (optional)

Dual-link DVI outputusing Mini DisplayPort to Dual-Link DVI Adapter supports 30-inch Apple Cinema HD Display (optional)

HDMI outputusing a third-party Mini DisplayPort to HDMI Adapter

Input

• Full-size backlit keyboard with 78 (U.S.) or 79 (ISO) keys, including 12 function keys and 4 arrow keys (inverted “T” arrangement)

• Multi-Touch trackpad for precise cursor control; supports inertial scrolling, pinch, rotate, swipe, three-finger swipe, four-finger swipe, tap, double-tap, and drag capabilities

Processor and memory

• 2.4GHz or 2.53GHz Intel Core i5 processor with 3MB shared L3 cache; or 2.66GHz Intel Core i7 processor with 4MB shared L3 cache

• 4GB (two 2GB SO-DIMMs) of 1066MHz DDR3 memory; two SO-DIMM slots support up to 8GB

Storage

• 320GB or 500GB 5400-rpm Serial ATA hard drive; optional 500GB 7200-rpm hard drive, or 128GB, 256GB, or 512GB solid-state drive

• 8x slot-loading SuperDrive (DVD±R DL/DVD±RW/CD-RW)

• Maximum write: 8x DVD-R, DVD+R; 4x DVD-R DL (double layer), DVD+R DL (double layer), DVD-RW, DVD+RW; 24x CD-R; 10x CD-RW

• Maximum read: 8x DVD-R, DVD+R, DVD-ROM; 6x DVD-ROM (double layer DVD-9), DVD-R DL (double layer), DVD+R DL (double layer), DVD-RW, DVD+RW; 24x CD

Battery and power

• Built-in 77.5-watt-hour lithium-polymer battery

• 85W MagSafe Power Adapter with cable management system

• MagSafe power port

Electrical and operating requirements

• Line voltage: 100V to 240V AC

• Frequency: 50Hz to 60Hz

• Operating temperature: 50° to 95° F

  • (10° to 35° C)

• Storage temperature: -13° to 113° F

  • (-24° to 45° C)

• Relative humidity: 0% to 90% noncondensing

• Maximum operating altitude: 10,000 feet

• Maximum storage altitude: 15,000 feet

• Maximum shipping altitude: 35,000 feet
