4-Core

• 3.6GHz quad-core Intel Core i3

• 6MB shared L3 cache

• Configurable to:

• • 6-Core

    3.2GHz 6-core Intel Core i7

    Turbo Boost up to 4.6GHz

    12MB shared L3 cache

6-Core

• 3.0GHz 6-core Intel Core i5

• Turbo Boost up to 4.1GHz

• 9MB shared L3 cache

• Configurable to:

• • 6-Core

    3.2GHz 6-core Intel Core i7

    Turbo Boost up to 4.6GHz

    12MB shared L3 cache

8GB

• of 2666MHz DDR4 SO-DIMM memory

• Configurable to:

  • 16GB, 32GB, or 64GB

128GB

• PCIe-based SSD

• Configurable to:

  • 256GB, 512GB, 1TB, or 2TB SSD

256GB

• PCIe-based SSD

• Configurable to:

  • 512GB, 1TB, or 2TB SSD

512GB

• PCIe-based SSD

• Configurable to:

  • 1TB or 2TB SSD

Intel UHD Graphics 630

Support for the following combination of maximum concurrent display setups:

• • Up to three displays:

    • Two displays with 4096-by-2304 resolution at 60Hz connected via Thunderbolt 3 plus one display with 4096-by-2160 resolution at 60Hz connected via HDMI 2.0

  • Up to two displays:

    • One display with 5120-by-2880 resolution at 60Hz connected via Thunderbolt 3 plus one display with 4096-by-2160 resolution at 60Hz connected via HDMI 2.0

Thunderbolt 3 digital video output supports

• Native DisplayPort output over USB-C

• Thunderbolt 2, DVI, and VGA output supported using adapters (sold separately)

HDMI 2.0 display video output

• Support for one display with 4096-by-2160 resolution at 60Hz

• DVI output using HDMI to DVI Adapter (sold separately)

Built-in speaker

3.5 mm headphone jack

HDMI 2.0 port supports multichannel audio output

Four Thunderbolt 3 (USB-C) ports with support for:

• DisplayPort

• Thunderbolt 3 (up to 40 Gb/s)

• USB 3.1 Gen 2 (up to 10 Gb/s)

• Thunderbolt 2, HDMI, DVI, and VGA supported using adapters (sold separately)

Two USB-A ports (up to 5Gb/s)

HDMI 2.0 port

Gigabit Ethernet port (configurable to 10Gb Ethernet)

3.5 mm headphone jack

Wi-Fi

• 802.11ac Wi-Fi wireless networking

• IEEE 802.11a/b/g/n compatible

Bluetooth

• Bluetooth 5.0 wireless technology

Ethernet

• 10/100/1000BASE-T Gigabit Ethernet (RJ-45 connector)

• Configurable to 10Gb Ethernet (Nbase-T Ethernet with support for 1Gb, 2.5Gb, 5Gb, and 10Gb Ethernet using RJ-45 connector)

Height: 1.4 inches (3.6 cm)

Width: 7.7 inches (19.7 cm)

Depth: 7.7 inches (19.7 cm)

2.9 pounds (1.3 kg)

Line voltage: 100–240V AC

Frequency: 50Hz to 60Hz, single phase

Maximum continuous power: 150W

Operating temperature: 50° to 95° F (10° to 35° C)

Storage temperature: –40° to 116° F (–40° to 47° C)

Relative humidity: 5% to 90% noncondensing

Operating altitude: tested up to 16,400 feet (5000 meters)Typical acoustical performance: Sound pressure level (operator position): 5 dBA at idle
